Sol-Max 15-12KW-AIO
All-in-One Hybrid Inverter
Sol-max One inverter is our flagship all in one hybrid inverter for off grid, backup power and advanced grid tie use.
Features
Features & Specifications
Engineered for better surge rating, smart load management, and safer operation.
High Surge Power
20kW (84A) 1-second surge at 240V with 100% imbalanced load support for real-world 120V surge loads.
5-in-1 Design
AIO means 5-in-1: inverter, charger, MPPT, Smart Panel, and Sub Panel. Competitors only offer 3-in-1.
3 MPPT Trackers
15kW max PV input, 600VDC max, wide 70-540V window with integrated PV disconnect.
Smart Load Outputs
Three programmable 120/240VAC outputs (60A, 50A, 30A) for load shedding and opportunity loads.
Hydraulic-Magnetic Breakers
CBI hydraulic-magnetic breakers on all inputs and outputs for easier code compliance and safer operation.
Off-Grid Ready
Built-in AGS for generator support Excellent surge capacity for motor loads.
Power Capacity
- •11.4 kW (47.5A) continuous output (with PV) / 10.0 kW (42A) on battery alone
- •20 kW (84A) 1 second surge at 240 volts, 13 kW (108A) 1 second surge on 120 volt leg
- •15 kW max PV array input
- •Up to 9 units stackable in 240 volts 90kW. 3 units for 208vac three phase 30 kW
- •Efficiency: 98% PV-to-AC / 94.5% battery-to-AC / 96.6% CEC weighted
- •Full power to 6,500ft elevation, derated above
- •Full power to 45°C (113°F), derated above
Physical
- •IP65/NEMA 3R (outdoor-rated)
- •-25°C to 60°C operating range
- •108 lbs (49 kg)
- •38.3" x 16.5" x 10.7"
Battery Compatibility
- •40-64VDC (Lithium-ion Sol-max or pylontech closed loop, lithium-ion open loop or Lead-acid open loop)
- •Plug and play with Sol-max batteries — no programming or DIP switches or firmware incompatibility
- •210A max charge/discharge current / 250A hydraulic-magnetic breaker
Output & Loads
- •120/240V split-phase or 208V 3-phase (3 units)
- •100A Grid input/Load output
- •3 programmable SmartLoad AC outputs (60A, 50A, 30A)
- •CBI hydraulic-magnetic breakers on all inputs and outputs
Solar Input
- •3 MPPT trackers (90VDC min - 600VDC max, 30A/22A/22A per MPPT)
- •15,000W max PV input
- •AC coupling PV input (50A)
- •Integrated PV disconnect switch
Grid & Backup
- •100A grid pass-through / <10ms transfer time
- •Generator integration (automatic two-wire start)
Safety & Compliance
- •UL1741SB, UL1741 PCS, IEEE1547, HECO SRD 2.0 certified
- •Arc fault, ground fault, rapid shutdown included
- •Built in surge suppression
Resources
Documents & Resources
Spec sheets, manuals, installation guides, and certifications for the Sol-Max 15-12KW-AIO.
Add-Ons
Accessories
Compatible accessories to complete your Sol-Max 15-12KW-AIO installation.
WiFi/Ethernet Dongle
Included with every inverter
Custom wiring trough
Connects inverter to Powerflo16 battery, includes busbars for combining up to 4 batteries.
Lightning Surge Suppressor package
DC and AC surge protector package for lightning protection. Mounts on top of wiring trough behind inverter for compact installation. Coming Soon
